Bitfocus Companion

Control Cliqer from Bitfocus Companion with the built-in Cliqer module, auto-installed and ready to use.

Controlling Cliqer from Bitfocus Companion surfaces

Cliqer integrates with Bitfocus Companion, the popular open-source button-control software for live production. The Cliqer module is installed automatically when Cliqer detects Companion on your system, so there is no manual setup.

Auto-Install: The Cliqer module is bundled with the app and placed in Companion's modules folder on launch. When a newer version ships, the app updates it in place.

Availability: The module (v1.2.2) ships with the Cliqer desktop app 2.0.7 and later (and the legacy 1.x app). It requires Bitfocus Companion 4.2 or newer.

How It Works

Cliqer runs two loopback servers that the module connects to: an HTTP action API on 127.0.0.1:24601 for button actions, and a WebSocket on 127.0.0.1:9052 that streams live timer updates and app state for feedbacks and variables.

Same machine: Both servers are loopback-only, so Companion must run on the same computer as Cliqer for actions to fire and feedbacks to update.

Setup

Install Bitfocus Companion (4.2 or newer) and launch it at least once
Launch Cliqer, it drops the Cliqer module into Companion's modules folder
Restart Companion once so it picks up the module, then add a Cliqer connection (it points at 127.0.0.1, action API port 24601)

Automatic updates: Each time Cliqer launches it checks whether a newer module version is bundled and updates the modules folder in place. If Companion is holding the current module open, the refresh is deferred to a later launch rather than left half-written.

Available Actions

The module provides 19 actions, grouped by category:

Category	Actions
Click	Left Click, Right Click
Timer	Start / Pause Timer, Reset Timer, +1 / +2 / +5 Minutes, −1 / −2 / −5 Minutes
Presets	Timer Preset 1 / 2 / 3 / 4 (5, 10, 15, 20 minutes)
Callers	Caller to Program (choose caller 1–9), Clear Program (cut to black)
Control	Stop Screen Share, Toggle Program NDI Output, Toggle Timer NDI Output

How presets resolve: The four preset actions send fixed durations of 5, 10, 15 and 20 minutes. Cliqer selects the matching preset in your Timer panel when one is configured for that number of minutes, otherwise it sets the timer directly to that duration.

Caller, share and NDI actions act on the presentation host. Taking a caller to program, clearing program, stopping a share and the NDI toggles run against the Cliqer app on this machine; the caller mixer is a macOS feature. An action with nothing to act on returns success and does nothing.

Feedbacks

Feedbacks change a button's appearance based on live state. The module defines 11 feedbacks:

Feedback	True when
Timer Running	The timer is actively counting
Timer Stopped	The timer is paused
Timer Overtime	The timer has passed 0:00 in countdown mode
Timer Yellow (Warning Phase)	The timer is nearing its limit
Timer Red Flash (At Zero / Overtime)	Flashes as the timer hits zero / runs into overtime
Caller On Air (Program)	The selected caller is live on the program bus
Caller Connected	The selected caller slot has a connected caller
Screen Share Active	A screen share is on the program feed
Program NDI Output Active	The program NDI output is on
Timer NDI Output Active	The timer NDI output is on

The module also defines a Timer Green (Talk Phase) feedback that Cliqer 2.x does not currently drive, so it stays inactive.

Variables

The module exposes 14 variables for use in button text and triggers. Reference them by the connection label, for example $(Cliqer:timer_display) when the connection is named Cliqer:

Variable	Description	Example
`timer_display`	Current timer value (MM:SS)	`14:30`
`timer_minutes`	Minutes component	`14`
`timer_seconds`	Seconds component	`30`
`timer_state`	Timer state	`running` / `stopped`
`preset1_label` … `preset4_label`	Preset durations (MM:SS)	`05:00`
`program_caller`	Name of the caller currently on program	`Jane`
`callers_count`	Connected callers	`3`
`viewers_count`	Audience / viewers	`128`
`presenters_count`	Connected presenters	`2`
`room_id`	Current room ID	`ABC123`
`room_url`	Shareable room link	`https://cliqer.io/ABC123`

Presets

The module ships ready-made button presets so you can build a control surface by dragging, grouped into the same categories as the actions: Click, Timer, Presets, Callers and Control. Drop them onto a Companion page for instant slide, timer, caller and output control.

Platform Support

Platform	Auto-Install Location
macOS	`~/Library/Application Support/companion/modules/`
Windows	`%APPDATA%\companion\modules\`

The module is placed in a cliqer-cliqer-<version> folder inside that directory (for example cliqer-cliqer-1.2.2). When Cliqer installs an update it removes the previous version folder first, so only the current version remains.

Troubleshooting

Module Not Appearing in Companion

Ensure Companion is installed and has been launched at least once before Cliqer
Companion scans its modules folder only at startup, so restart Companion once after Cliqer's first launch and the Cliqer connection type will appear
The Refresh modules button in Companion refreshes its online store, not the local modules folder, so restart Companion to surface a freshly installed module

Actions Not Firing

Confirm the connection targets 127.0.0.1 on action API port 24601
A legacy Cliqer 1 build briefly served this API on port 2222, which broke stock module actions; module v1.2.2 with Cliqer 2 uses 24601, so use the default port
Only one Cliqer instance can own the local ports on a machine — see the Stream Deck notes

Timer Feedbacks or Variables Not Updating

The live timer and app-state feed uses the loopback WebSocket on port 9052, so Companion must run on the same computer as Cliqer
Slide and timer actions can still succeed over HTTP even when the feed is not connected, so if buttons fire but feedbacks stay static, check the connection status in Companion
